Ordering Codes                                                                                            ALK-ASN

Operating Voltage                                                                                      17-41Vd.c.

Low Power Mode (typ)                                                                             120μΑ

Quiescent Current (typ)                                                                           400μ Α

Alarm Current                                                                                              9.1mA

Transmission Method                                                                               Digital Communications Using ESP

Operating Temperature Range                                                              -10°C to +50°C

Storage Temperature Range                                                                  -20°C to +60°C

Maximum Humidity                                                                                   95%RH - Non Condensing (at 40°C)

Ingress Protection Rating                                                                         IP42

Colour/Case Material                                                                                White/ABS

Weight (g)                                                                                                      90 (Ecluding base)

Diameter (mm) / Height with base (mm)                                          100/46

Compatible Bases                                                                                       YBN-R/3(WHT),YBO-BS (WHT),YBO-BSB(WHT),YBO-R/SCI(WHT)

Base Fixing Centres (mm)                                                                        48~74
